Woodward 8200-1302 Digital Governor Operator Panel
Here’s a quick overview of the 8200-1302 – this HMI panel serves as the primary interface for steam turbine operators. It’s commonly used in power generation plants and industrial facilities where turbine speed/load control needs constant monitoring. The 8.4” LCD display combined with physical buttons makes it particularly useful during critical adjustments when touchscreen reliability might be compromised.
Technical Specifications
| Attribute | Specification |
|---|---|
| Brand | Woodward |
| Power Supply | AC/DC (88-132 Vac or 90-150 Vdc) |
| Display | 8.4” Color LCD |
| Environmental Rating | IP54, -30°C to 70°C operating temp |
| Certifications | ATEX, UR E10, Overvoltage Category III |
| Interface | 34-key membrane keypad |
Application Context
This panel typically works with Woodward’s 505D Digital Governor systems in natural gas compressor stations or refinery settings. We’ve seen it used alongside turbine models like the 505D-2000 and 505D-3000 series. When customers ask about compatible parts, we often pair it with 8200-1301 communication modules or 8521-0312 control cards.
Our Support
We keep these in stock across our Hong Kong and Singapore warehouses – last month alone shipped 12 units to a Southeast Asian power plant. All units come with our standard 1-year warranty covering functional defects. For current pricing or replacement advice, feel free to reach out via:
- WhatsApp: +86 190-6659-1275
- Email: abbdcs36@gmail.com
*Note: Actual delivery time varies by location – we recently delivered 3 units to Texas within 5 business days using our DHL contract rates. For urgent needs, mention your project timeline when contacting.
