Siemens 6FX8002-8QN08-1AH2 Industrial Control Module

This precision-engineered control module serves as the backbone for high-accuracy motion control applications. Designed for seamless integration with Siemens’ SINAMICS drive systems, it excels in environments requiring precise synchronization of multiple axes – think robotic assembly lines or CNC machining centers. The 24V DC operating voltage and 50kHz output frequency make it particularly suitable for applications demanding rapid response times and stable performance under varying loads.

Technical Specifications
Manufacturer	Siemens AG
Model Number	6FX8002-8QN08-1AH2
Voltage Range	24V DC ±15%
Output Frequency	0.1-50 kHz
Certifications	CE, UL, RoHS
Dimensions	125 × 80 × 25 mm
Weight	380g

In real-world applications, we’ve seen this module deliver exceptional performance in automotive manufacturing lines where ±0.01mm positioning accuracy is required. One customer in the semiconductor industry reported a 22% reduction in calibration time after switching to this module’s advanced signal processing architecture. It pairs particularly well with our inventory of complementary components:

• Siemens SINAMICS S120 drive systems
• Simatic S7-1500 PLC controllers
• 6SL3210-5FE10-7UF0 AC inverters
• 6FX8002-8QN08-1AA0 communication modules

Our engineering team recently helped a plastics molding client integrate this module into their existing system – the result was a 17% improvement in cycle time stability. The built-in diagnostics interface proved invaluable during commissioning, allowing quick identification of signal integrity issues in the field wiring.
