Allen Bradley 1336-QOUT-SP23A Output Test Module

This specialized tool helps engineers verify VFD performance in industrial environments. I’ve seen technicians use it to diagnose motor drive issues in conveyor systems and HVAC installations where precise frequency control matters. Unlike basic multimeters, it tests dynamic load scenarios that mimic real production line conditions.

We’ve supplied these modules for pulp & paper mill retrofits where drive reliability impacts 24/7 operations. One mining client used it to troubleshoot 1336-BC series drives controlling ore crushers. Similar testing needs appear in food processing plants with Allen Bradley’s 1336 IMPACT drives. The module’s USB interface works with DriveExplorer software for waveform analysis.

Our inventory includes compatible VFD models like 1336-BRF-EN, 1336-GM-EN, and 1336-VR drives. For system integrators, we recommend checking availability for配套 components like 1336-RPM-C and 1336-SPMC modules that often get tested together.

While this module handles most 1336 series drives, we’ve encountered rare compatibility issues with early 1336-AB models. If you’re working with legacy systems, let us check specific version compatibility before purchasing. Current pricing available upon request via contact channels above.
